| Sensor |
|---|
| Scintillator | Direct-Deposit CsI |
| Active Area | 430 × 356 mm |
| Image Matrix Size | 3072 × 2560 |
| Pixel Pitch | 140 μm |
| Image Quality |
|---|
| Limiting Resolution | 3.57 lp/mm |
| MTF (Typical) | 75% (1 lp/mm), 44% (2 lp/mm), 26% (3 lp/mm), 19% (3.5 lp/mm) |
| DQE (Typical) | 70% (1 lp/mm), 61% (0.5 lp/mm), 55% (1.5 lp/mm), 46% (3 lp/mm) |
| Maximum Linear Dose | 70 μGy |
| Dynamic Range | >80 dB |
| Lag | < 0.002% (60 seconds after exposure) |
| A/D Conversion |
|---|
| A/D Conversion | 16 bits |
| Communication Interface |
|---|
| Communication Interface | Gigabit Ethernet, WiFi (2.4/5 GHz) |
| Image Acquisition Time | 2 - 4 s |
| Exposure Control | F.AED, Manual Sync, Software Sync |
| Environmental |
|---|
| Operating Environment | Natural Cooling |
| Temperature Range | Operating: 5 - 35°C, Storage: 20 - 55°C |
| Humidity Range | Operating: 30 - 75% RH, Storage: 10 - 90% RH (Non-condensing) |
| Mechanical |
|---|
| Dimensions | 460 × 384 × 15 mm |
| Weight | ~3.7 kg |
| Housing Material | High-strength aluminum alloy w/ carbon fiber imaging surface |
| Power |
|---|
| Maximum Power | Max. 36VA |
| Power Supply | 100 - 240V AC |
| Frequency | 50/60 Hz |
